  1. An AI agent's plan beside the timber roof it is designing

    Agent Workflow: a Timber Roof from One Prompt

    Agent workflow

    An AI agent reads the roof from an IFC model, solves it, checks it to Eurocode 5, picks the section, then writes the report and the drawings and hands them over for review.
  2. Eight beams and frames with their bending moment diagrams

    Push It. Pull It. Watch It Deflect.

    Interactive

    Push and pull eight classic beams and frames and watch them deflect live. A finite element model runs in your browser.
  3. A CLT floor rippling as a walker crosses it

    Feel the Floor

    Interactive

    Draw a walk across a timber floor, put your coffee down and watch the floor answer. A plate model of four floors runs in your browser.
  4. Frei Otto's Tanzbrunnen tent at night

    Pull Frei Otto's 1957 Tent

    Interactive

    Pull the Tanzbrunnen tent and watch it bounce: a form-found minimal surface membrane on frame masts, solved live in your browser.
  5. A diaphragm wall beside a staged excavation, with its wall movement and bending moment

    Staged Excavation

    Solver

    Dig a pit behind a diaphragm wall stage by stage and watch the wall move and its bending moment grow. A 2D soil solver runs in your browser.
  6. A 3D portal frame loaded towards buckling

    Load It Past the Critical Point

    Solver

    Load a 3D portal frame and a compressed plate beyond buckling and follow their response, solved with a nonlinear solver benchmarked against Abaqus.
  7. A steel frame skeleton built from OBJ geometry

    Modeling: From Geometry to Members

    Tool

    From OBJ geometry to a surface point cloud to a skeleton of structural members, merged with AI.
  8. A slab on columns coloured by its deflection

    Real-Time Slab Design

    Tool

    Change the mesh, the load and the thickness of a slab on columns and watch its deflection update as you drag.
  9. A reinforced concrete column beside its elevation and section drawing

    Drawings Automation

    Tool

    Resize a reinforced concrete column and its elevation and section drawing redraw with it.
  10. A tall frame swaying under lateral load with two outriggers

    Outrigger Optimization

    Tool

    Move two outriggers up and down a tower and search for the levels that stiffen it most.
  11. A frame beside a ground acceleration record and its displacement response

    Dynamic Analysis: Earthquake

    Tool

    Shake a frame with a ground acceleration record and follow its top displacement through time.
  12. A thin cylinder crushed into buckled folds

    Nonlinear Buckling of a Cylinder

    Tool

    A thin cylindrical shell crushed in compression until it folds. Show its stresses or compare with the initial shape.
  13. A concrete portal frame pushed sideways with its push-over curve

    Nonlinear Concrete Push-Over

    Tool

    Push a reinforced concrete portal frame sideways, step by step, and watch it crack, yield and form plastic hinges.
