Nonlinear Analysis in Seconds, Not Hours

I couldn't sleep for two weeks.

Not because something was broken. Because something finally started to work in a way that felt like a real shift for finite element analysis.

Nonlinear analysis has always been one of the places where structural engineering software slows down. It is powerful, but expensive. It can capture large displacements, second-order effects, buckling, and instability, but the price is usually long solve times, careful setup, and convergence behavior that can turn one model into an afternoon.

That cost changes how engineers work. Nonlinear analysis becomes something you reserve for late-stage validation, specialist studies, or cases where the risk is already obvious. It is too heavy to use while the design is still moving.

The Shift We Are Building Toward

With Awatif, we are trying to make nonlinear analysis fast enough to enter the workflow much earlier.

The goal is not to replace trusted FEM tools. Abaqus and similar solvers have earned their place in engineering practice. The goal is different: make reliable nonlinear feedback available while engineers are still exploring options, testing assumptions, and shaping the structure.

If a nonlinear result takes hours, it is a final check. If it takes seconds, it becomes part of the design conversation.

The Benchmark

To test the solver seriously, we benchmarked Awatif against Abaqus on three buckling-sensitive frame-element problems:

• a cantilever column under combined tip load,
• a 3D portal frame with a top-joint load, and
• a clamped-clamped IPE 300 column with prescribed end displacement.

These are not marketing animations. They are benchmark cases designed to compare displacement response, solver iterations, residual error, and convergence behavior.

The Result

Across the three benchmark cases, Awatif closely reproduced the Abaqus displacement response. The reported displacement differences stayed at or below 1.00%.

The performance difference is where things get interesting. Compared with Abaqus, Awatif reduced the solver iteration count by:

• 51,438.8× for the cantilever column,
• 42,105.9× for the portal frame, and
• 94.5× for the IPE 300 column.

For the simple cantilever column benchmark, Awatif closely matched the displacement response while needing 5 iterations instead of 257,194. That is more than four orders of magnitude fewer iterations.

What This Means

Faster nonlinear solving changes when engineers can ask nonlinear questions.

Instead of waiting until the end of a project to ask whether buckling behavior, second-order effects, or large displacement response may become important, engineers can bring those checks into earlier modeling and design workflows.

That is the part that kept me awake. Not one benchmark number in isolation, but the possibility of moving nonlinear analysis from a late-stage specialist task into everyday engineering iteration.

Read the White Paper

We wrote up the benchmark cases, assumptions, displacement comparisons, iteration counts, residual errors, and conclusions in a short nonlinear solver white paper.

If you are building engineering software in AEC, mechanical, marine, energy, or another simulation-heavy industry, I am open to collaborations. Send me a message and I will show you a live demo.
